New Vintage USA 79078-78 Features:

NVU brings you a new way to install aftermarket gauges in your 73-79 Ford Truck dash. Ditch those old square gauges and go with a new look altogether. NVU's exclusive CNC laminate brackets and cover pieces create the look you want while providing the info on the vitals you need. Create the look you want while retaining most of the factory dash appearance, switches and layout. The exclusive CNC laser-cut mounting bracket features turn signals, hi beam and warning lamps, designed to match the factory viewing angle to kelp you keep your eye on the vitals. Requires removal of factory bezel "uprights" and installation of NVU cover pieces (included) 6 gauge kits include a factory-match 73-10 ohm fuel gauge to match standard tanks. Polished stainless steel bezels bring some pop to the dash.
A Symphony of Colors and Craftsmanship
Experience a symphony of colors with multi-hued dials and spun hubs that elevate aesthetics to unparalleled heights. The intricate details exude sophistication, setting the M-108 series apart.
Craftsmanship in Every Detail
Unparalleled refinement defines the M-108 series. Polished stainless steel bezels radiate luxury, while real glass lenses add authenticity that redefines instrument craftsmanship.
Illuminate Your Journey
LED backlighting infuses a mesmerizing visual aura while ensuring effortless readability, even in low-light conditions. The luminous allure breathes life into your dashboard.
Unleash Innovative Excellence with Patented Phoenix Technology
Experience the revolutionary Phoenix technology, exclusive to NVU. This innovation brings built-in indicators, performance timers, auxiliary inputs, settable odometer mileage, and more at your fingertips, elevating your driving experience.

LED backlighting
Bold styling
Easy programming and setup
Built-in indicators (Turn signal, hi beam, warning lights)
3-7/16" Speedometer 140 MPH programmable with 1 auxiliary input
3-7/16" Tachometer 8,000 RPM with TWO auxiliary inputs
2-1/16" Fuel gauge, programmable (0-90, 240-33, 73-10, 40-250, 0-30, 10-180, 20-150 ohm settings)
Temperature gauge 140-280 F
Oil pressure gauge 0-100 PSI
Voltmeter 9-17 V
2 ea AMP connector harnesses
2 ea Programming buttons
Bushing kit
Oil pressure sender 99100-04 (1/8-27 NPT, 240-33 Ω
Temperature sender 99230-04 (1/8-27 NPT, NVU hi match)
73-79 F100 Mounting bracket
*Speed sender may be required check your application

• Speedometer Gauge Included: Yes
• Tachometer Gauge Included: Yes
• Water Temperature Gauge Included: Yes
• Oil Pressure Gauge Included: Yes
• Voltage Gauge Included: Yes
• Fuel Gauge Range: Yes
• Fuel Sender Included: No
• Bezel Included: No
• Bracket Included: Yes
• Speed Sender Included: No
• Temperature Sender Included: Yes
• Oil Pressure Sender Included: Yes
• Wiring Harness Included: Yes
• Indicator Lamps: Yes
• Gauge Style: Analog
• Gauge Dial Color: Black
• Gauge Number Color: White
• Gauge Pointer Color: Red
• Bezel Finish: Stainless
• Gauge Lens: Flat Glass
