800-FM-AN10-SS Stainless Flow Meter [-10 AN Stainless]

Name: 800-FM-AN10-SS Stainless Flow Meter [-10 AN Stainless]
Brand: RACEPAK
SKU: 806-80FMAN10SS
Price: 1499.95 USD
Availability: InStock

^$1,499⁹⁵

1 left in stock

Ships on Nov 02, 2026

Lowest Price Guarantee

Flow Meter

Turbine-Style Fuel/Clutch Flow Sensor

-10 AN Stainless Construction

2–25 GPM Range

Methanol Compatible

The 800-FM-AN10-SS Stainless Flow Meter is a turbine-style sensor for monitoring fuel or hydraulic clutch systems in high-performance applications. Designed for -10 AN systems, it provides accurate flow readings from 2–25 GPM and is fully compatible with methanol-based fuels. Ideal for confirming fuel pump health, verifying timer operation, and tracking lean-out behavior when paired with Racepak DataLink math channels.

Racepak 800-FM-AN10-SS Features:

Stainless steel -10 AN construction
Supports 2–25 GPM flow rates
Compatible with methanol fuels
Works with Racepak data systems and math channels
Suitable for fuel and hydraulic clutch applications

Emissions Note:

This part is legal for sale or uses on Emissions Controlled Vehicles, Uncontrolled (Non-Emissions Controlled) Vehicles, and Racing Use Only Vehicles because it does not affect vehicle emissions and is not covered by emissions regulations.

CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART

Racepak's V-Net (Vehicle Network) technology is a "smart data" transfer network that gives you the ability to transmit multiple signals from each sensor using a single cable. This network creates a system where individual components interact with each other; providing you with a simpler, more compact system. Whether using a single gauge set-up or a full-blown data acquisition system, all components are attached using modular snap-together connectors.

Racepak's Sensors, Modules and Controllers are designed for use with Racepak V-Series data loggers and dashes, or as direct replacements and are available in a wide range of monitoring parameters. Each item is made to meet or exceed OE specifications and constructed of the highest-quality materials for long-term durability. Engineered for the harsh conditions of the racing environment.
