Vehicle Info NeededWILWOODPART NUMBER: 950-140-17956-R
140-17956-R AERO4-DM Direct-Mount Truck Rear Brake Kit
$2,24166
Ships on 09/16/2026
Lowest Price Guarantee- AERO4-DM Direct-Mount Truck Rear Brake Kit
- Sprinter Awd 2500 22-24
- 13.25 Rotor
- Red
- W/Lines
Wilwood 140-17956-R Features:
AERODM Four Piston calipers were designed for the specific purpose of providing a direct mount, large capacity braking solution with large diameter rotors for heavy weight and extreme duty vehicles. For trucks and SUV’s, it provides big stopping power for towing, off-road, and enhanced braking with wheel and tire upgrades. Kits listed for specific vehicles are fully compatible with OE master cylinder output and ABS function. OEM style 1 piece 13.25in to 13.56in diameter rotors provide maximum cooling for sustained high heat durability.
Part TypeDisc Brake Kit
BrandWILWOOD
Package Height15.5
Package Width15.75
Package Length16.0
Weight80.0 PG
Part CategoryPerformance Parts
Caliper Piston Quantity4
Caliper TypeLug
Rotor Outside Diameter13.25 in.
Rotor Thickness1.10 in.
Wheel Stud Size0.59 in.
Spindle IncludedNo
Component TypeRear Brake Kits - Street Performance
Master Cylinder IncludedNo
Caliper FinishRed Powder Coat
Hub IncludedNo
Solid Or Vented Type RotorVented
Brake Hose Dot ApprovedYes
Caliper ColorRed
Brake Booster IncludedNo
QuantitySold as a kit
Mounting Hardware IncludedYes
Length Pintle RetrievedRear Kits
Bolt Circle Diameter6 x 5.118 in.
Brake TypeDisc
Minimum Wheel Diameter17 in.
Brake Lines IncludedYes
Piston MaterialStainless
Surface TypeGT Slotted
Part FitmentSemi Universal
Flange Offset0.00 in.
Rotor MaterialIron
Vendor Part Number140-17956-R
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
