JEGS 635290

JEGS Stainless Steel Universal Brake Line Kit 71pc

555-635290

Free Shipping Ships

$279.99
JEGS Stainless Steel Universal Brake Line Kit 71pc $279.99
Out of stock
3 left in stock
QTY
Stainless Steel Universal Brake Line Kit
  • 71pc
    Includes:
  • (1) 20' 3/16" Brake Line Coil
  • (6) -03AN Bulkhead Fitting Weld-On Tabs
  • (4) 18" -03AN Brake Hoses
  • (14) Fittings
  • (20) -03AN Tube Nuts
  • (20) -03AN Tube Sleeves
  • Items You May Also Consider

    JEGS 635290 Details

    Stainless Steel Universal Brake Line Kit

      Includes:
    • (1) 20' SS Brake Line Coil
    • (4) Stainless Steel -03AN to 1/8" NPT Fittings
    • (4) Stainless Steel -03AN Brake Hoses 18"
    • (6) Brake Line Tabs
    • (6) -03AN Bulkhead Nuts
    • (2) Stainless Steel -03AN Bulkhead Straight Fittings
    • (2) Stainless Steel -03AN Bulkhead 90° Fittings
    • (2) Stainless Steel -03AN Bulkhead Tee Fittings
    • (4) Stainless Steel -03AN to 1/8" NPT 90°
    • (20) Stainless Steel -03AN Tube Nuts
    • (20) Stainless Steel -03AN Tube Sleeves

    Specifications:

    Color
    Silver
    Overall Length (in.)
    18
    Brake Hose Outer Material
    Braided stainless steel
    Assembled
    Yes
    Hose End 1
    -3 AN
    Hose End 1 Angle
    Straight
    Hose End 1 Attachment
    Female threads
    Hose End 2
    -3 AN
    Hose End 2 Angle
    Straight
    Hose End 2 Attachment
    Female threads
    Inside Diameter
    N/A
    Material
    Braided Stainless Steel
    Outside Diameter
    N/A
    Size
    3AN
    Shipping Weight:
    3.6
    Package Height:
    17.2
    Package Depth:
    2.4
    Package Width:
    16.9

    JEGS Stainless Steel Universal Brake Line Kit has the parts needed to install new 3/16" stainless steel brake lines with braided stainless brake hose on most vehicles. Instructions show suggested line routing for traditional rear axles or independent rear suspension. The brake line coil and fittings are made from 304 grade stainless steel.

    • Order caliper or wheel cylinder adapters (sold separately)
    • Use -03AN caliper adapters with the correct size thread for calipers/wheel cylinders.

    635290 is rated 5.0 out of 5 by 1.
    Rated 5 out of 5 by from Awesome kit!.... This is an awesome kit. It had everything I needed and more. I was very happy with the whole kit and will be buying a few more for some other cars I have to do.
    Date published: 2017-05-26
    • y_2019, m_8, d_16, h_20
    • bvseo_bulk, prod_bvrr, vn_bulk_2.0.13
    • cp_1, bvpage1
    • co_hasreviews, tv_0, tr_1
    • loc_en_US, sid_10001_10001_2812811, prod, sort_[SortEntry(order=RATING, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
    • clientName_jegs

    Can the 18inch long brake hose be shortened?

    Asked by: ToledoDan
    You would need to buy the an fittings and re-make it if you shorten the line.
    Answered by: Rusty B
    Date published: 2018-06-12
